| Material | Aluminum foil (semi-hard, flat) or paper |
| Maximum Roll Diameter | 700 mm |
| Maximum Material Width | 320 mm |
| Material Thickness | 0.04 ± 0.005 mm |
| Corrugated Edge Width After Pressing | 3 mm - 10 mm |
| Corrugation Height | 3 mm - 6 mm (customizable) |
| Sizing Length | Freely adjustable |
| Production Speed (Max) | 0 - 30 sheets/min |
| Power Supply | 380V, 50Hz |
| Compressed Air Requirement | 0.6 m³/min |
| Machine Dimensions (L * W * H) | 3800 * 950 * 1395 mm |
| Motor Configuration | Three-phase motor |
| Mechanical Parts Treatment | Shafts: electroplated hard chrome; Others: decorative nitro-iron and black treatment |
| Pneumatic Components Brand | Jiahe brand, Harbin bearings |
| Instrument Installation | Reasonable layout, easy to remove |
